What is a Bobbin Wound Filter? A Comprehensive Guide

A bobbin wound filter is a highly efficient filtration system primarily used in swimming pools, water parks and other aquatic environments. These filters play a critical role in maintaining water clarity and cleanliness by removing dirt, debris and contaminants from the water. Unlike traditional filters, which are often made from flat materials, a bobbin wound filter is constructed using a specialized winding process that enhances its strength, durability and filtration efficiency.

Design of a Bobbin Wound Filter

The unique construction of a bobbin wound filter involves layers of glass fiber or polymer that are wound around a cylindrical core. This winding process forms a robust shell that is resistant to high pressure and extreme conditions. The continuous winding creates a tightly compact structure, leaving minimal gaps for contaminants to pass through, ensuring a high level of filtration.

The bobbin winding technique gives the filter housing its strength, making it capable of withstanding pressure changes and the force of flowing water, which is essential for high-volume swimming pools and large aquatic systems. The filter is then coated with a protective layer, often resin, that improves its resistance to chemical corrosion, UV rays and general wear and tear. This construction makes bobbin wound filters ideal for long-term use in outdoor environments where they are exposed to elements such as heat, sunlight and chlorine-treated water.

Inside the filter, the filtration media—usually sand or other fine materials—captures particles as water flows through the system. These particles can range from dirt and algae to finer contaminants like oils and bacteria. The filtration media in bobbin wound filters is typically backwashed regularly to remove trapped contaminants, making maintenance relatively easy.

Functionality of a Bobbin Wound Filter

The primary function of a bobbin wound filter is to remove contaminants from pool water, ensuring that the water remains clear, safe and hygienic for swimmers. The water is pumped through the filtration media inside the bobbin wound shell, where debris and impurities are trapped.

Here’s how the filtration process works:

  1. Water Inflow: Pool water enters the filter through the inlet pipe and is distributed evenly over the filtration media.
  2. Filtration Process: As water flows through the tightly packed layers of sand or other filtration media, contaminants like dirt, leaves and algae are trapped. Smaller particles such as oils and bacteria are also captured in this process.
  3. Clean Water Outflow: Once the contaminants are trapped, clean and filtered water is returned to the pool through the outlet pipe.
  4. Backwashing: To clean the filter, the system is reversed through a process called backwashing, where water flows backward through the filter to flush out collected debris, thereby extending the lifespan of the filtration media and maintaining optimal performance.

The overall design and functionality of bobbin wound filters make them suitable for both residential and commercial swimming pools. They are able to handle large volumes of water with minimal resistance, ensuring consistent filtration without significant energy consumption.



The Benefits of Using Bobbin Wound Filters for Swimming Pools

When it comes to choosing the right filtration system for your swimming pool, bobbin wound filters offer several advantages over other types of filters. These benefits make them a popular choice for pool owners who prioritize efficiency, durability and ease of maintenance.

1. High Durability

One of the most significant advantages of bobbin wound filters is their durability. The glass fiber or polymer material, wound in layers, gives the filter a high tensile strength, allowing it to withstand extreme pressure and adverse conditions. This makes them ideal for larger swimming pools or commercial setups where the filtration system has to process vast amounts of water daily.

The outer coating of resin or a similar protective material adds an extra layer of resistance against corrosion and UV degradation. This is particularly important for outdoor swimming pools, where the filter is exposed to sunlight and fluctuating weather conditions.

2. Improved Filtration Efficiency

Thanks to the compact winding process, bobbin wound filters offer superior filtration capabilities. The dense winding reduces the size of any gaps that contaminants could pass through, resulting in finer filtration of pool water. This is crucial for keeping the water not just visibly clean but also safe by removing smaller particles, including bacteria and oils, which can affect water quality.

3. Energy-Efficient Operation

Bobbin wound filters are designed to offer minimal resistance to water flow, which reduces the strain on the pool’s pump system. The low-resistance design helps in optimizing the energy usage of the pool filtration system, which is an important factor for pool owners looking to reduce their operational costs.

4. Low Maintenance

While all filters require periodic maintenance, bobbin wound filters are easier to maintain compared to some other types of filters. Their ability to undergo backwashing ensures that the filter media can be cleaned without the need for frequent replacement. This backwash process extends the filter’s operational life and reduces the need for manual cleaning, making it convenient for busy pool owners or large commercial operations.

5. Long-Term Cost Savings

Though the initial investment in a bobbin wound filter may be higher than some other filter types, the durability, efficiency and low maintenance requirements result in long-term cost savings. The filter’s extended lifespan and reduced need for repairs or replacements make it a cost-effective solution for pool owners.



Choosing the Right Bobbin Wound Filter: A Buyer’s Guide

When selecting a bobbin wound filter for your swimming pool, several factors need to be considered to ensure that you are choosing the most suitable model for your needs. This buyer's guide will help you navigate the options and make an informed decision.

1. Pool Size and Volume

The size of your swimming pool is one of the most important factors to consider when choosing a bobbin wound filter. Larger pools require filters with a higher flow rate and filtration capacity. Make sure to calculate the total volume of water in your pool and select a filter that can handle that volume efficiently.

For instance, a small residential pool may only require a filter with a lower flow rate, while a commercial pool with heavy usage will need a more powerful model capable of processing higher volumes of water quickly.

2. Flow Rate

The flow rate of a filter is measured in gallons per minute (GPM) or liters per minute (LPM) and refers to the amount of water the filter can process in a given time. It’s important to match the flow rate of the filter with the capacity of your pool pump to avoid overloading either the pump or the filter. A filter with too low of a flow rate can cause inefficient filtration, while one with too high of a flow rate may lead to premature wear.

3. Filter Media

Different bobbin wound filters use various types of filter media, such as sand, diatomaceous earth (DE) or cartridges. Sand filters are the most common choice due to their simplicity and cost-effectiveness. However, if you need finer filtration, DE filters are more efficient at capturing smaller particles but come with a higher maintenance requirement. Consider your pool’s specific needs and the level of filtration required when selecting the type of media.

4. Durability and Material Quality

The quality of the materials used in the construction of the filter plays a big role in its longevity. Filters made from high-quality fiberglass or polymer materials with a durable resin coating are more resistant to wear and tear, making them a better long-term investment. Ensure that the filter you choose is made from robust materials that can withstand the conditions specific to your pool environment, such as exposure to harsh chemicals or UV rays.

5. Ease of Maintenance

While bobbin wound filters are generally low-maintenance, it’s essential to consider how easy the filter is to clean and maintain. Look for filters with accessible backwashing systems that can be operated without much hassle. Additionally, consider the cost and availability of replacement parts, as this can impact the long-term ease of maintenance.

6. Brand Reputation and Warranty

Lastly, consider the reputation of the manufacturer and whether they offer a solid warranty. Trusted brands often offer higher-quality filters and provide warranties that cover the product for several years, giving you peace of mind regarding your investment.

When selecting a bobbin wound filter, it's essential to opt for reputable brands known for quality and reliability in filtration products. Medley Pool is highly regarded for offering high-quality bobbin wound filters that cater to various filtration needs. Their products are designed for durability and efficiency, making them a popular choice among pool owners and water treatment professionals.

Medley Pool filters are crafted from robust materials, ensuring they withstand the harsh conditions often present in pool environments. With a focus on customer satisfaction, they provide excellent support and guidance for selecting the right filter for your specific requirements. Choosing  Medley Pool  products means investing in a reliable filtration solution that helps maintain the cleanliness and clarity of your water.

Bobbin wound filters are an excellent choice for both residential and commercial swimming pools, thanks to their durability, high filtration efficiency and energy-saving capabilities. Their design and functionality make them ideal for maintaining clean and safe pool water, while their ease of maintenance and long-term cost savings make them a worthwhile investment.

By carefully considering factors such as pool size, flow rate, filter media, durability and maintenance requirements, you can choose the right bobbin wound filter to meet your pool’s specific needs. With the right filter in place, you’ll enjoy clear, healthy water and a pool system that runs smoothly for years to come.
